Spécifications

X-axis travel: 500 mm
Y-axis travel :320 mm
Z-axis travel: 400 mm
Spindle nose to table: 120-520 mm
Spindle center to column guide-way face:  360 mm
High speed feeding of X,Y, axis:  18000 mm /min
High speed feeding of Z axis:  18000 mm /min
Feeding speed:  1-4000 mm /min
Size of table:  800×320 mm
Max. loading capacity of table:  300 kg
T-slot NO./width /distance of table: 3/14/100
Spindle max. speed: 10000 rpm
Main motor rated power:  3.7 kw
Spindle nose taper BT30
Max. diameter of tools:  Φ100 mm
Max. length of tools:  200 mm
Max. weight of tools:  5 kg
Time of changing tools:  6(Umbrella)/2(Round) s
Positioning accuracy of X/Y/Z axis:  0.02(GB)0.012(Real) mm
Re-positioning accuracy of X/Y/Z axis:  0.012(GB)0.008(Real) mm
Pneumatic press:  0.6 MPa
N.W 2500 kg
Overall dimension:  1600×1840×2110 mm
